Schneider LC1F185 Tesys F Contactors – 3-Pole, AC-3 Rated, 185A, No Coil Included

Description

Main
Range TeSys
Product name TeSys F
Product or Component Type Contactor
Device short name LC1F
contactor application Resistive load, Motor control
Utilisation category AC-3, AC-4, AC-1
poles description 3P
power pole contact composition 3 NO
[Ue] rated operational voltage <= 690 V AC 50/60 Hz
<= 460 V DC
[Ie] rated operational current

275 A 104 °F (40 °C)) <= 440 V AC-1
185 A 131 °F (55 °C)) <= 440 V AC-3
Motor power kW

100 kW at 415 V AC 50/60 Hz (AC-3)
100 kW at 440 V AC 50/60 Hz (AC-3)
110 kW at 500 V AC 50/60 Hz (AC-3)
90 kW at 380…400 V AC 50/60 Hz (AC-3)
55 kW at 220…240 V AC 50/60 Hz (AC-3)
110 kW at 660…690 V AC 50/60 Hz (AC-3)
33 kW at 400 V AC 50/60 Hz (AC-4)
