Description
Maximum Horsepower
2000 hp @ 14 VDC EFI (1000 hp on Methanol)
2400 hp @ 16.5 VDC EFI (1200 hp on Methanol)
GPH/PSI Range: 200-250 GPH / 0-80 PSI
Considerations: If your actual horsepower is close to the Max Hp limit and/or you are considering power adder, see part# 34706 or 34712 Mechanical Pump
Features
- All billet body pumps are 100% serviceable/repairable
- Self Priming
Pump may be mounted above fuel cell
Vertical or horizontal mount - Breakaway coupling prevents pump/motor damage in the event of fuel contamination
- All internal components are 100% metallic
No plastics or composite materials. Our internal pumping elements are made of high speed tool steel and bronze. This results in the longest lasting, highest quality, most durable pumps available. - Body machined from billet aluminum
- For carbureted and injected engines
- Provides Consistent Performance with no fall-off in flow
- Precise fuel delivery
- Blades self-compensating for wear
- 6 lbs
Weldon Pumps offer the widest range of fuel compatibility.
Gasoline – Methanol – Nitro Methane – Diesel – Ethanol – All racing fuels
Requires appropriate bypass regulator. We suggest an Aeromotive 13113, a Weldon 2040 or a Weldon 2047
A minimum of a -10AN return line is recommended.
