Tial V60 60mm Turbo Wastegate

Description

TiAL V60 60mm Wastegate

The 60mm TiAl is the choice of most pro racers!!!

Simply the lightest and best working 60mm Wastegate on the market!!!

If your running a big cubic inch motor, running a big turbo or running a lot of boost???

Then the TiAL 60mm waste gate is what you need!!!

• High temp NiCrFe based alloy is used for valve and 347SS valve housing will offer longer product life compared to competing designs.
• High temperature silicone Nomex reinforced actuator diaphragm.
• 17-7 PH Stainless Steel actuator spring gives consistent pressure at high temperature, resist “relaxing” at temperature to 900F (483C).
• Nitronic 60 Stainless Steel is used for the valve seat, and valve bushing.
• All Stainless Steel hardware.
• Mating weld flanges are 304L
• Color anodized aluminum actuator (Silver, Red, Blue, Purple, Black).
• Race proven at Le Mans
• Flows 330CFM @ 1psi differential pressure

Whats in the Box???

Included with every Tial V60:

V60 Assembly
V60 Valve Seat
2 TiAL Air Fittings
Inlet Flanges and Clamps
Outlet Flanges and Clamps
