Description
Cop 3060 Rock Drill & Drifter
simba m7c, boomer m2c, boltec mc Underground Drill Rig
roc d7 11, roc l8, flexiroc t40, flexiroc t35, roc l6, flexiroc d60sf, flexiroc d60lf, roc l8lf, roc d7 11+ Surface Drill Rig Models.
| Type |
MBT 3560 |
| Product group |
Sensors |
| Product Name Description |
Temperature transmitter |
| Ambient temperature max. [°C] |
85 °C |
| Ambient temperature max. [°F] |
185 °F |
| Approval |
CE |
| CE mark |
Yes |
| China RoHS compliance |
Out of scope |
| Connection material |
Stainless steel |
| Connection standard |
ISO 228 |
| Connection type |
G |
| Contains batteries |
No |
| EEE category |
5 small equipment (any external dimension < 50 cm) |
| Electrical conn. Male/Female |
Male |
| Electrical connection |
M12 x 1 |
| Electrical connection size |
4 pin |
| Electrical connection standard |
IEC 61076-2-101 |
| Enclosure rating IP |
IP67 |
| EU RoHS compliance |
Yes with exemptions |
| EU RoHS exemption clause |
6(c) |
| In scope of WEEE |
Yes |
| Insertion length [in] |
2.76 in |
| Insertion length [mm] |
70 mm |
| Insertion type |
Fixed |
| Measuring range [°C] [max] |
150 °C |
| Measuring range [°C] [min] |
-40 °C |
| Measuring range [°F] [max] |
302 °F |
| Measuring range [°F] [min] |
-40 °F |
| Output signal [mA] [max] |
20 mA |
| Output signal [mA] [min] |
4 mA |
| Packing format |
Single |
| Process connection Male/Female |
Male |
| Process connection material |
Stainless steel |
| Process connection size |
1/2 |
| Process connection standard |
ISO 228-1-A |
| Process connection type |
G |
| Protection tube diameter [in] |
0.315 in |
| Protection tube diameter [mm] |
8 mm |
| Protection tube material |
AISI 316 TI |
| Quantity per packing format |
13 pc |
| REACH Candidate List substances |
Lead (CAS no. 7439-92-1) |
| SCIP dossier no. |
8127e7d9-3431-4421-a02a-bab746bc2e4f |
| SCIP dossier product name |
Sensor MBT 3560 |
| Sensor elem. resistance [Ohm] |
1000 Ohm |
| Sensor element tolerance |
< ± 1% FS |
| Sensor element type |
Pt |
| Sensor Insert |
Fixed |
| Supply voltage [V] DC [max] |
32 V |
| Supply voltage [V] DC [min] |
10 V |
| Temperature range [°C] [max] |
200 °C |
| Temperature range [°C] [min] |
-50 °C |
| Temperature range [°F] [max] |
392 °F |
| Temperature range [°F] [min] |
-58 °F |
| Transmitter setting range [°C] [max] |
150 °C |
| Transmitter setting range [°C] [min] |
-40 °C |
| Transmitter setting range [°F] [max] |
302 °F |
| Transmitter setting range [°F] [min] |
-40 °F |
| Transmitter type |
Integrated |
| Type designation |
MBT 3560-0000-0070-62-815 |
